- Size: 43CBM
- Place of Origin: China
- Brand Name: SOCMA
- Model Number: HNF-120 (CPCD120)
- Weight: 18000.000 kg
POS | ITEM DESCRIPTION | UNIT | HNF-120 |
Character | Rated Capacity | kg | 12000 |
Load Centre | mm | 600 | |
Front Overhang | mm | 860 | |
Wheelbase | mm | 3000 | |
Weight | Self weight | kg | 18000 |
Axle load, full loaded (front/rear) | kg | 24215/2785 | |
Axle load, without loaded (front/rear) | kg | 6375/8625 | |
Chassis | Tyre, front |
| 10.00x20/16PR |
Tyre, rear |
| 10.00x20/16PR | |
Wheels, numbers front/rear(x=driving wheel) |
| 4×/2 | |
Wheel tread, front | mm | 1677 | |
Wheel tread, rear | mm | 2013 | |
Basic dimension | Mast Tilt Angle (front/rear) | ° | 6°/12° |
Mast height (fork lowered) | mm | 3070 | |
Lifting height | mm | 3000 | |
Mast height (fork lift) | mm | 3865 | |
Overall length (with fork) | mm | 6055 | |
Overall width | mm | 2300 | |
Fork size | mm | 90x180x1200 | |
Carrier width | mm | 2280 | |
Min. groundclearance-mast, full loaded | mm | 225 | |
Min. groundclearance-center of wheel base | mm | 350 | |
Min. turning radius | mm | 4300 | |
Parameter | Speed (full loaded/without load) | km/h | 23/26 |
Max. lifting speed (full loaded/without load) | m/s | 310/340 | |
Gradeability (full loaded/without load) | % | 25 | |
Service brake |
| Disc brake | |
Engine | Brand |
| |
Rated power | KW | 97 | |
Rated rotor speed | min-1 | 2200 | |
No.of Cylinder | cm3 | 6 | |
Others | Manual gear box |
|
|
